Overview
Connected home and IoT products pack sensors, radios, and control boards into small enclosures, which means internal cabling has to be compact without compromising signal or power integrity between modules.
Design & Construction
Compact Interconnect Wiring
Fine-gauge conductors and low-profile connectors keep internal cabling compact for space-constrained smart speaker, hub, and sensor enclosures, with wire count and routing matched to the customer’s PCB layout.
Sensor & Module Connectors
JST, Micro-Fit, and FPC jumper connector families are supported for board-to-board and sensor-to-controller interconnects, keeping mating cycles consistent across production lots.
Manufacturing Process
Built under our ISO 9001 quality system with RoHS 3 compliant materials and fast prototype turnaround to keep pace with connected-product development cycles.
Typical Applications
- Smart speaker and hub internal wiring
- IoT sensor node cabling
- Smart lock and video doorbell cabling
- Home automation controller interconnects
- PCB-to-PCB jumper cabling
Common installations include Smart speaker and hub internal wiring, IoT sensor node cabling, and Smart lock and video doorbell cabling, where signal integrity, EMI control, and compact flex-rated construction are the primary design drivers. The same base design can also be adapted for Home automation controller interconnects and PCB-to-PCB jumper cabling with minor changes to connector type or cable length.
Technical Specifications
Standard configurations are available with the following technical specifications; custom configurations outside these ranges can be discussed with our engineering team. Wire Gauge: AWG 28 – 22. Conductor Count: 2 – 16 circuits. Insulation: PVC/TPE, RoHS 3 compliant. Voltage Rating: Up to 24V DC. Temp Range: -20°C to +80°C. Connector Options: JST, Micro-Fit, FPC jumpers. Compliance: RoHS 3, CE marking, FCC-compatible construction.
Quality & Certification
Manufactured under ISO 9001:2015 certification, RoHS 3 compliant, with CE marking and FCC-compatible construction available for RF-enabled connected devices.
Customization & Lead Time
Standard lead time for the Smart Home & IoT Device Interconnect Cabling is 3–4 weeks prototype, 10–15 days production reorder. Connector type, cable length, and conductor configuration can be customized to match your exact application, including connector type, cable length, and shielding configuration to match your device’s board layout and enclosure design. Contact our engineering team with your drawings or requirements for a project-specific quote.
Why XinHarness
IoT interconnect cabling scales on the same lines we use for broader consumer electronics production, from prototype through volume. See the Electronics industry page, or request a quote for your project. For related technical background, see our article on the benefits of twisted-pair wiring for reducing electromagnetic interference.
Frequently Asked Questions
Yes, shielded cable, braided or foil shielding, and ferrite options are available to control EMI/RFI in sensitive electronic applications.
We support a wide range of board-to-board, wire-to-board, and industry-standard connector families; provide your preferred connector part number or mating requirement and we will match it.
Yes, all our consumer and industrial electronics cable assemblies, including the Smart Home & IoT Device Interconnect Cabling, are manufactured using RoHS 3 and REACH-compliant materials.
