Wiring that moves with a robot arm or machine axis fails differently than static panel wiring — it fatigues at the flex point. This harness is built specifically for continuous-flex, cable-chain duty on robotics and moving-axis machine tools.
Design & Construction
Continuous-Flex Cable
Conductors use fine-stranded copper with a continuous-flex-rated PUR jacket designed for cable-chain routing, combining power and signal circuits in a single hybrid harness where the machine design allows.
Strain Relief & Sealing
Connector interfaces are sealed to IP67-IP68 with reinforced strain relief at the flex boot, sized to the specific bend radius of the customer’s cable chain or drag chain routing.
Manufacturing Process
Harnesses are built under our ISO 9001 quality system with flex-rated materials validated against millions of duty cycles, and 100% electrical testing on every production run.
Typical Applications
- Six-axis robotic arm wiring
- CNC machine tool cable-chain harnesses
- Automated guided vehicle (AGV) power/signal cabling
- Gantry and linear-axis system wiring
- Conveyor and pick-and-place equipment harnesses
Common installations include Six-axis robotic arm wiring, CNC machine tool cable-chain harnesses, and Automated guided vehicle (AGV) power/signal cabling, where chemical and abrasion resistance for continuous duty in plant-floor conditions are the primary design drivers. The same base design can also be adapted for Gantry and linear-axis system wiring and Conveyor and pick-and-place equipment harnesses with minor changes to connector type or cable length.
Technical Specifications
Standard configurations are available with the following technical specifications; custom configurations outside these ranges can be discussed with our engineering team. Wire Gauge: AWG 24 – 12. Conductor Count: 2 – 40 circuits, hybrid power/signal. Insulation: Continuous-flex-rated PUR jacket. Temp Range: -30°C to +90°C. IP Rating: IP67-IP68. Flex Life: 10,000,000+ cycles (cable-chain duty). Standard: UL Recognized, CE marked.
Quality & Certification
Manufactured under ISO 9001:2015 certification with UL Recognized component construction and CE marking, with IP67-IP68 rated connector options for wash-down or dusty factory environments.
Customization & Lead Time
Standard lead time for the Heavy-Duty Robotic & Machine Wiring Harness is 5–6 weeks prototype, 3 weeks production. Connector type, cable length, and conductor configuration can be customized to match your exact application, including connector type, cable length, and environmental sealing to match your specific machine or enclosure design. Contact our engineering team with your drawings or requirements for a project-specific quote.
Why XinHarness
We deliver flex-rated, EMI-shielded harnesses validated for millions of duty cycles to robotics OEMs and machine builders, backed by 100% electrical testing on every run. See the Industrial industry page, or request a quote for your project. For related technical background, see our article on the role of relays and fuses in complex wiring harness systems.
