Overview
Life-critical equipment like dialysis machines and ventilators demands cable assemblies with redundant reliability, since a single connection failure can directly affect patient safety.
Design & Construction
Redundant, Fault-Tolerant Circuit Design
Dual-path power circuits and reinforced strain relief reduce single-point failure risk on equipment where continuous operation is critical, with conductor sizing matched to sustained current draw.
Biocompatible, Leak-Tested Connectors
Biocompatible connector materials and moisture-sealed housings protect against fluid exposure near dialysis and perfusion circuits, with every assembly leak- and continuity-tested before release.
Manufacturing Process
Assembled in an ISO 13485-certified cleanroom environment with full lot traceability and 100% electrical testing, supporting life support OEMs through rigorous design-transfer and validation processes.
Typical Applications
- Dialysis machine control and sensor wiring
- Ventilator and respiratory equipment cabling
- ECMO and perfusion system interconnects
- Patient monitor backup power wiring
- Life support cart and mobile unit cabling
Common installations include Dialysis machine control and sensor wiring, Ventilator and respiratory equipment cabling, and ECMO and perfusion system interconnects, where biocompatibility, electrical safety, and continuous fail-safe operation are the primary design drivers. The same base design can also be adapted for Patient monitor backup power wiring and Life support cart and mobile unit cabling with minor changes to connector type or cable length.
Technical Specifications
Standard configurations are available with the following technical specifications; custom configurations outside these ranges can be discussed with our engineering team. Wire Gauge: AWG 30 – 18. Conductor Count: 4 – 36 circuits. Insulation: Biocompatible PVC / TPE. Temp Range: -20°C to +105°C. Redundancy: Dual-path critical power circuits. Sealing: Moisture-sealed, leak-tested connectors. Testing: 100% continuity and dielectric test.
Quality & Certification
Manufactured under ISO 13485 and ISO 9001 certification, with complete documentation and validation support packages suitable for Class II/III medical device submissions.
Customization & Lead Time
Standard lead time for the Dialysis & Life Support Equipment Cable Assemblies is 5–7 weeks prototype, 2–3 weeks production reorder. Connector type, cable length, and conductor configuration can be customized to match your exact application, including connector type, cable length, and sterilization compatibility to match your device’s specific design requirements. Contact our engineering team with your drawings or requirements for a project-specific quote.
Why XinHarness
The same cleanroom line and 100% test coverage used for our diagnostic and infusion cable programs supports dialysis and life support OEMs through rigorous design-transfer and validation processes. See the Medical industry page, or request a quote for your project. For related technical background, see our article on the role of potting and conformal coating in wire harnesses.
Frequently Asked Questions
Medical assemblies including the Dialysis & Life Support Equipment Cable Assemblies are manufactured under ISO 13485 quality management for medical device manufacturing.
Yes, biocompatible and autoclave-sterilizable materials are available depending on the application and device contact requirements.
Yes, connector type, cable length, shielding, and sterilization compatibility can all be tailored to your specific medical device requirements — share your design specifications for a custom quote.
