Overview
Ground support equipment bridges aircraft systems with airport infrastructure, requiring rugged cable assemblies that handle frequent connect/disconnect cycles in outdoor tarmac conditions.
Design & Construction
Heavy-Duty, Weather-Rated Cable
UV-stable, weather-rated jacketing withstands outdoor tarmac exposure and temperature extremes across ground power, air start, and towing equipment.
High-Cycle Connector Durability
Connectors are rated for thousands of connect/disconnect cycles between aircraft and ground equipment, with keyed designs that prevent incorrect mating under time pressure.
Manufacturing Process
Built under AS9100D quality management with cycle-life and environmental testing, supporting GSE manufacturers and airport ground handling equipment programs.
Typical Applications
- Ground power unit (GPU) cabling
- Air start unit interconnects
- Aircraft tow tractor wiring
- Ground communication headset cabling
- De-icing truck control harnesses
Common installations include Ground power unit (GPU) cabling, Air start unit interconnects, and Aircraft tow tractor wiring, where flight-critical reliability and stringent weight optimization are the primary design drivers. The same base design can also be adapted for Ground communication headset cabling and De-icing truck control harnesses with minor changes to connector type or cable length.
Technical Specifications
Standard configurations are available with the following technical specifications; custom configurations outside these ranges can be discussed with our engineering team. Wire Gauge: AWG 14 – 4. Conductor Count: 2 – 20 circuits. Insulation: UV-stable, weather-rated jacketing. Temp Range: -40°C to +105°C. Cycle Life: Thousands of connect/disconnect cycles. Voltage Rating: 28V DC / 115V AC ground power. Connector Type: Keyed, high-cycle aerospace ground connectors.
Quality & Certification
Manufactured under AS9100D and ISO 9001 certification, with cycle-life validation matched to high-frequency ground equipment connect/disconnect use.
Customization & Lead Time
Standard lead time for the Aircraft Ground Support Equipment (GSE) Cable Assemblies is 5–7 weeks prototype, 2–3 weeks production reorder. Connector type, cable length, and conductor configuration can be customized to match your exact application, including MIL-spec connector alternatives and shielding options for specific avionics or airframe integration requirements. Contact our engineering team with your drawings or requirements for a project-specific quote.
Why XinHarness
GSE cable assemblies draw on the same rugged connector and cycle-life testing standards used across our aerospace and industrial equipment programs. See the Aerospace industry page, or request a quote for your project. For related technical background, see our article on the impact of extreme temperatures on wire harness performance.
Frequently Asked Questions
All aerospace harnesses, including the Aircraft Ground Support Equipment (GSE) Cable Assemblies, are manufactured under AS9100D quality management and can be built to MIL-DTL-27500 wire and connector specifications on request.
Every Aircraft Ground Support Equipment (GSE) Cable Assemblies unit undergoes continuity, insulation resistance, and dielectric withstand testing, with additional environmental and vibration testing available for flight-critical applications.
Yes. Connector types, wire gauge, shielding, and routing length can all be customized to match your specific airframe and installation requirements — contact our engineering team with your drawings or specifications.
